With the sleek design and customizable options, our High Speed Roll-up Doors can be tailored to meet the specific needs of your business. Whether you require enhanced security features, fire resistance, or simply a door that can keep up with your high-speed operations, it offers a perfect solution.
Feel free to contact CI Industry PVC door manufacturer for further queries.
CI Industry, one of the distinguished high speed roll up door manufacturers, is committed to providing innovative and top-tier industrial doors to meet the diverse needs of commercial and industrial clients. Contact us to explore a variety of sizes and customization options that will perfectly complement your home's architectural design.
Product Name | High Speed Roll-up Door |
Maximum Door Size | W6500mm*H6000mm |
Opening speed | 0.8 - 2.0 m/s, adjustable |
Closing speed | 0.6 - 1.0 m/s, adjustable |
Operation way | Remote control, wall switch, Magnetic loop, Radar, Pull Rope Switch, Signal lamp |
Emergency Operation | Available with manual crank |
Curtain Thickness | 0.8 / 1.0 / 1.2 / 1.5mm |
Hardware Material | Frame and Cover Box - Galvanized steel / 304 stainless steel |
Track Guide - Galvanized Steel / 304 Stainless Steel / Aluminum extrusion | |
Wind Resistance Bar - Aluminum Extrusion | |
Curtain - SIOEN high strength polyester textile fiber | |
Vision panel - 1.5mm thick transparent PVC | |
Motor Brand | SNMA, SEW, SIEMENS,SEJ,SERVO |
Motor Power | 0.75kw - 5.50kw |
Input Voltage | 220V 50HZ/380V 50HZ |
PLC Brand | SIEMENS / MIT-SUBISHI / OMRON /KEWEI |
Inverter / AC Driver | MIT-SUBISHI,SIEMENS,SHIHLIN |
Control Box Finish | Powder coated steel /304 stainless steel |
Safety Performance | Infrared photo sensor, Safety airbag edge protection |
Tolerance Frequency | 2 times/min, Inverter opening 2500-3000 times/day |
Safety Class | IP55 |
Wind Resistance | Class 5-8 (Beaufort Scale) |
Operating Life | 500,000 cycles |
Working Temperature | -25 °C to 65 °C |
Warranty | 1 year for electric parts, 5 years for mechanical parts |
Maximum Size: 6500mm x 6000mm
Opening Speed: Up to 1.9m/s, variable
Temperature Resistance: -25°C to +65°C
Wind Resistance: Available up to Class 8 (Beaufort Scale)
Weight: Canvas 950g / M2
Steel Construction: Galvanized Steel with Full Cover
Vision Window: Available
