Lithium-ion forklifts offer a range of advantages that improve productivity, reduce costs, and enhance safety in material handling operations. They have a long service life, reducing the frequency of replacements and overall costs in the long run.
Currently we have CPD15/CPD18/CPD20/CPD25 available. Feel free to contact us for further queries.
| G2 | ||||
| Model | CPD15 | CPD18 | CPD20 | CPD25 |
| Load Capacity (k) | 1500 | 1800 | 2000 | 2500 |
| Load Center (mm) | 500 | 500 | 500 | 500 |
| Dimension | ||||
| Max Lifting Height (mm) | 4014 | 4014 | 4030 | 4030 |
| Overhead Guard Height (mm) | 2140 | 2140 | 2170 | 2170 |
| Overall Length(without fork) (mm) | 2140 | 2140 | 2432 | 2432 |
| Overall Width (mm) | 1120 | 1120 | 1160 | 1160 |
| Min. Outside Turning Radius (mm) | 1860 | 1860 | 2070 | 2070 |
| Wheels, Chassis | ||||
| Tyre (front) | 6.5-10-12PR | 6.5-10-12PR | 6.5-10-12PR | 7.00-12-14DL |
| Tyre (rear) | 16*6-8-10PR | 16*6-8-10PR | 16*6-8-10PR | 18×7-8-14PR |
| Type | pneumatic | pneumatic | pneumatic | Pneumatic |
| G2 | |||
| Model | CPD30 | CPD35 | CPD38 |
| Load Capacity (k) | 3000 | 3500 | 3800 |
| Load Center (mm) | 500 | 500 | 500 |
| Dimension | |||
| Max Lifting Height (mm) | 4217 | 4217 | 4217 |
| Overhead Guard Height (mm) | 2180 | 2180 | 2180 |
| Overall Length(without fork) (mm) | 3639 | 3644 | 3932 |
| Overall Width (mm) | 1225 | 1225 | 1225 |
| Min. Outside Turning Radius (mm) | 2215 | 2215 | 2250 |
| Wheels, chassis | |||
| Tyre (front) | 28*9-15-14PR | 28*9-15-14PR | 28*12.5-15-24PR |
| Tyre (rear) | 200/50-10 | 200/50-10 | 200/50-10 |
| Type | pneutmatic | pneutmatic | solid |
Strong performance, excellent and efficient.
Three configurations of S/M/H can be selected at will. M/H configuration models have superior overall performance, comparable to fuel trucks, and significantly improved operating efficiency.
Intelligent safety, comprehensive protection.
Curve deceleration function: automatic deceleration function in the curve, which can reduce the risk of overturning in the curve.
Steering wheel to start steering: the steering wheel can directly start the steering function, and provide the required amount of fuel according to the speed of the steering wheel.
Color screen instrument: Chinese and English switching, battery display, tyre angle and other information at a glance, more functions, more convenient operation.
